MARUTI SPUN PIPE is Gujarat’s Largest Manufacturer

RCC Pipes

Gujarat’s Largest Manufacturer
RCC Pipes (300 mm to 3500 MM NP3,NP4 class)
RCC Pipes

Reinforced Concrete Pipes, abbreviated as RCC Hume pipes are extensively used for water mains, sewers, culverts, irrigation supply, and in cable management. Owing to its properties subsuming high tensile strength, durability, leak-proof nature, low maintenance, sturdiness, RCC Pipes are widely preferred in the construction industry.

We are manufacturing various sizes of RCC pipes by vertical vibrated casting technology as per IS: 458 under controlled environment and quality management system

Specifications
Class Description Conditions Where Normally Used
NP2 Reinforced concrete, light-duty, non-pressure pipes For drainage and irrigation use, for cross drains/ culverts carrying light traffic
NP3 Reinforced concrete, medium-duty, non-pressure pipes For drainage and irrigation use, for cross drains/ culverts carrying medium traffic
NP4 Reinforced concrete, heavy-duty, non-pressure pipes For drainage and irrigation use, for cross drains/ culverts carrying heavy traffic
Internal Diameter Length NP3 Class NP4 Class
Wall Thickness Strength Test Required for Three Edge Bearing Test Wall Thickness Strength Test Required for Three Edge Bearing Test
MM MM MM KN/Linear RMT MM KN/Linear RMT
300 2000 50 15.50 50 26.64
350 2500 55 16.77 55 29.8
400 2500 60 19.16 60 33.9
450 2500 65 21.56 65 63.9
500 2500 70 23.95 70 40
600 2500 75 28.74 75 46.3
700 2500 85 33.53 85 52.2
800 2500 95 38.32 95 59.3
900 2500 800 43.11 800 66.3
1000 2500 115 47.90 115 72.6
1200 2500 125 57.48 125 88.3
1400 2500 140 67.06 140 99.10
1600 2500 165 76.64 165 109.90
1800 2500 180 76.64 165 109.90
2000 2500 190 95.80 190 131.50
2200 2500 210 105.40 210 -

Note: Concrete pipe shall have minimum compressive strength of 35N/mm2 at 28 Days.

Source: IS 458
